Mobile Handheld Computer M2SmartSE with HF-RFID

Mobile Handheld Computer M2Smart®SE HF-RFID

HF-RFID/NFC Reader

The M2Smart®SE mobile handheld computer with integrated HF RFID/NFC reader offers a robust and intelligent solution for mobile use with HF RFID.

Product Information

M2Smart®SE with HF-RFID

Flexible and modular for your RFID processes

Important Key Facts

  • Frequency range: 13.56 MHz
  • Approvals: CE, FCC, IC, CCC
  • Operating system Android™ Industrial+ where the main focus is on security aspects
  • Reliable plug and play feature for frequent module changes
  • Intuitive usability through common Android™ environment
  • Rugged housing design for rough everyday use
  • Combinable with all RFID and other modules such as keypads, handle, Imager (shortrange/midrange/longrange), etc.

In 2020, the M2Smart®SE mobile handheld computer received the iF Design Award, the German Innovation Award, and the Innovation Award of the State of Baden-Württemberg.
ACD gewinnt mit dem M2SmartSE diverse Innovationspreise

YouTube

By loading the video, you accept YouTube's privacy policy.
Learn more

Load video

Technical Data

All Data at a glance

HF-RFID
  • Integrated HF RFID/NFC Reader PN7150 with integrated firmware
  • Frequency range: 13.56 MHz
  • CE, FCC, IC, CCC
  • Special feature: Can be combined with all RFID modules from ACD
Supported RFID Protocols
  • NFC IP Modes: Reader NFC forum tag type 1 to 5, P2P active initiator and target, P2P passive initiator and target, reader/writer mode, peer to peer mode, and card emulation
  • Reader (PCD-VCD): ISO/IEC 14443A/B, ISO/IEC15693, MIFARE Classic/DESFire, Sony FeliCa
  • CARD (PICC): T4T-ISO/IEC14443A, ISO/IEC14443B, NFC FORUM T3T
System
  • NXP® i.MX8M Mini, 4x Cortex A53 (4x 1,8 GHz) and 1x Cortex M4 (1x 400 MHz)
  • 16 GB Flash, larger memory optionally available
  • 2 GB RAM, larger memory optionally available
  • Android™ Industrial+
Options
  • WLAN according to IEEE 802.11 a/b/g/n/ac/d/h/e/i/r/k/w/v (2,4 GHz/5 GHz) incl. BT-compatible close-range network 5.0
  • WLAN Security: WLAN Security:WEP, WPA, IEEE802.11i (Personal and Enterprise), WPA2, WPA2-PSK, 802.11x: authentication
  • SOTI® certification
Display
  • 5″ color TFT Display with LED backlight
  • 1280 x 720 pixels, 400 cd/m²
  • 3 Status LED
  • Capacitive, surface hardness 7H
Device
  • Housing: ABS/PC
  • Protection class: IP54/IP65
  • Device dimensions: 174 x 82 x 28 mm (L x W x D)
  • Weight: Ca. 390 g
  • Operating temperature: -20 °C bis 50 °C/-4 °F to 122 °F
  • Storage temperature: -20 °C bis 60 °C/-4 °F to 140 °
Keyboard
  • Side On-/Off key
Power supply
  • Quick-change rechargeable battery, li-ion with 22.8 Wh (6,000 mAh/3.8 V)
  • Docking station incl. battery charger for spare battery
Barcode scanner (as option)
  • Integrated in housing, side scanner buttons
  • 2D shortrange Imager SE4770 (IP65) or
  • 2D midrange Imager SE4750MR (IP54)

Product Equipment

Accessories

Dockingstation DS2Smart

DS2Smart® charging and transmission box

For charging the M2Smart®SE as well as a replacement rechargeable battery, with Ethernet and USB-Host interface.

Dockingstation DS2Smart

DS2Smart® charging box

For charging the M2Smart®SE as well as a replacement rechargeable battery.

DS2Smart Developerbox

DS2Smart® Developer box

Housing with LED Display for charging the M2Smart®SE, as well as charging a replacement battery, incl. led out USB cable for connection with a PC.

DS2Battery Charging box 2-fold

DS2Battery Charging box 2-fold

Housing with LED indicators for charging two spare batteries of the M2Smart®SE.

Ersatzakku plus

Replacement Battery Plus

Replacement Battery Plus (quick change battery with 22,8 Wh) for the Mobile Handheld Computer M2Smart®SE.

Module M2Key16 Logistics

M2Key16 Logistic

Attachable hard-shell keyboard with 16 keys as lower plug-on module for the M2Smart®SE, can be changed without tools.

M2Longange scanner module

M2Longrange

Attachable longrange scanner module (SE4850) as upper plug-on module, changing without tools.

modul-m2uhf-rfid-konfigurator

M2UHF-RFID Midrange

Pluggable UHF-RFID Midrange Module (ETSI, FCC/IC, SRRC) for reading and writing UHF-RFID tags as upper plug-on module for the M2Smart®SE, read range up to 6 meters, changing without tools.

M2Logistikschutzkappen

M2Logistics protection caps

Logistics protection cap set for the default delivered top and bottom plug-in module of the M2Smart®SE in order to increase fall protection.

Module M2Grip5 Configurator

M2Grip5

Handle for the M2Smart®SE incl. scanner button. Easy attachment and removal without tools is possible.

Module M2Grip5 Configurator

M2Grip5 SE

Handle for the M2Smart®SE incl. scanner button. Easy attachment and removal without tools is possible.

m2smart-se-accessories-bag-01

Bag with closure tab

Bag made of black fabric material with Velcro element for fixing the M2Smart®SE incl. swivel clip for fastening to the belt/waistband.

M2SmartSE bag for devices with handle

Bag

Bag made of black fabric material with Velcro element for fixing the M2Smart®SE for fastening to the belt/waistband.

M2SmartSE holster bag

Holster bag

Holster made of black fabric material for the M2Smart®SE incl. snaps for attachment to the belt. Suitable for devices with grip.

Kapazitiver Touchstift

Capacitive touch pen

Capacitive touch pen (length approx. 11 cm; diameter approx. 0.6 cm) for easy operation of the M2Smart®SE.

m2smart se accessories display protection film low reflection

M2Smart®SE display protection film 5 inch / low reflection

Low-reflection screen protector protects the display of the M2Smart®SE 5 inch.

m2smart se accessories display protection film

M2Smart®SE display protection film 5 inch

Display protection film protects the display of the M2Smart®SE 5 inch.

m2smartse-halterung-ram-mount

M2Smart®SE Holder incl. RAM Mount

Spring-loaded holder incl. RAM Mount (143 mm arm) for mounting the M2Smart®SE or M2Smart®SE with M2Key16 Logistics Module

Fahrzeug-Holstertasche

Vehicle Holster Bag

Vehicle holster bag for the M2Smart®SE or the M2Smart®SE with M2Key16 logistics module (with and without handle), which can be attached to a pillar on the vehicle.

Similar Products

Products that might also interest you

M2smart mobile handheld computer

Mobile Handheld Computer M2Smart®SE

Integrated HF-RFID/NFC Reader

In the age of Industry 4.0 and IoT, portable RFID readers are increasingly being used to flexibly perform individual read or write operations as required. As a specialist for mobile operating devices, ACD Elektronik GmbH takes this trend into account and presents a variant of the mobile handheld computer M2Smart®SE with integrated HF-RFID.

Security and long-term availability are the center of attention

Long-term availability and a clear focus on security aspects are to be particularly emphasized as characteristics of the Android™ embedded platform of ACD Elektronik. This means that customers can calculate with eight years of support for hardware and software and thus have a high investment security. All critical services and functions that could lead to unwanted data exchange with third parties have been eliminated without limiting the usual comfort of the Android™ system.

All relevant updates and security patches can be accessed via ACD support. A further advantage of the mobile handheld computer is the robust housing construction with high impermeability and a long-lasting battery that can be changed during operation without having to restart the device. The patented modularity as well as the operating system Android™ Industrial+ make the M2Smart®SE with HF-RFID a slim, yet very robust and efficient solution for use in a wide range of scenarios where RFID is required.
